A laboratory jaw crusher is a grinding instrument, which forcefully reduces size of solid materials. It is widely used by mining and metallurgical industries, chemical and ceramic industries and building material etc. STERICOX brings to you powerful jaw crushers for laboratory use. These laboratory jaw crushers have been designed for fast and reliable sample preparation in laboratory related to pharmaceutical, cement, coal, construction material, glass, granite ceramics, quartz, silicon and ores etc. These two models JC5 and JC6 are fast, reliable and known for durable construction and high productivity in its range of laboratory jaw crushers in the market today. These imported jaw crushers come choice of jaw plate of different materials such as stainless steel, manganese steel, tungsten carbide and zirconium oxide. With loads of features and competitive price; these laboratory jaw crushers meet toughest demands of primary crushing applications of different industries.
Our laboratory jaw crushers comprise of an anti-splash hopper, grinding chamber and two jaw plates. Material to be crushed is put into grinding chamber through feed hopper, which is removable. The crushing is processed between two jaw plates; one plate is fixed and other jaw plate keeps moving with the help of bent axle driven by continuous rotation of motor. The rocking motion jaw plate pushes material against fixed jaw plate that results size reduction of samples that falls into drawer receiver at the lower part of the machine. Gap between jaw plates can be adjusted with the help of rotating handle.
FEATURES & BENEFITS
- Models with final fitness < 2mm and < 0.5mm
- Zero set point adjustment feature
- Powerful industrial drive for size reduction
- Anti-splash design hopper
- In-built overload protection
- Removable feed hopper
- Easy to clean structure design
TECHNICAL SPECIFICATIONS
| Model |
JC5 |
JC6 |
| Feed size |
<90mm |
<40mm |
| Final fineness |
<2mm |
<0.5mm |
| Speed |
690rpm |
500-1000rpm |
| Collector capacity |
5L |
3L |
| Jaw plate width |
99mm |
59.5mm |
| Gap setting |
0 - 30mm |
0 - 11mm |
| Zero point adjustment |
Yes |
Yes |
| Rated power |
2.2KW |
1.1KW |
| Power supply |
415V, 50Hz |
220 Volts 50Hz |
| Instrument size(W*D*H) |
440 x 930 x 1090 mm |
450 × 630 × 490 mm |
| Jaw plate |
- Manganese steel
- Stainless steel
- Tungsten carbide
- Zirconium oxide
|
LARGE SIZE JAW CRUSHER
| MODEL |
CAPACITY (KG/HR) |
INLET SIZE (MM) |
FEED SIZE (MM) |
OUT-PUT GRANULARITY
(MM) |
SPINDLE SPEED (RPM) |
POWER (KW) |
| STXJC100*60 |
230-400 |
100*60 |
≤50 |
6-10 |
650 |
1.5 |
| STXJC100*100 |
200-1800 |
100*100 |
≤80 |
3-25 |
600 |
2.2 |
| STXJC125*100 |
200-1800 |
125*100 |
≤80 |
5-25 |
500 |
3 |
| STXJC100*150 |
200-1800 |
100*150 |
≤90 |
6-38 |
500 |
2.2 |
| STXJC150*125 |
400-3000 |
150*125 |
≤100 |
6-38 |
500 |
3 |
| STXJW150*250 |
700-5000 |
150*250 |
≤120 |
10-40 |
350 |
5.5 |
| STXJW60*100 |
45-550 |
60*100 |
≤50 |
1-10 |
290 |
1.5 |
| STXJW100*100 |
65-850 |
100*100 |
≤80 |
1-25 |
600 |
2.2 |
| STXJW100*125 |
300-2000 |
100*125 |
≤100 |
2-35 |
375 |
3 |
| STXJW150*125 |
500-3000 |
150*125 |
≤120 |
4-45 |
375 |
3 |
