Working Principle
Filtered storage cabinets are fitted with a turbine motor blower which draws air from outside; air brings hazardous vapor and fumes into the filtration assembly on top. This hazardous air goes through molecular filtration assembly and becomes fresh air. Discharged air is completely free from pollutants. This process keeps on running 24 hours.
We are filtered storage cabinet manufacturers in India. Our standard models come in small wall mounted and floor standing types. The mini filtered storage cabinet is wall mounted or you can keep this on bench for easy access. This small cabinet has only 2 shelves but fitted with all advanced features a filtered storage cabinet must have. Other two models are floor standing type and are made for large storage capacities. These cabinets come with 8 and 16 numbers of shelves. Doors are transparent and fitted with lock and keys. At bottom of the cabinet there is PP sump with is leak proof. These filtered cabinets are noise free, easy to installation and use and required almost no maintenance. In addition, we also make customized sizes on request. Our filtered chemical storage cabinets are supplied all over India at competitive price. We also export these cabinets to UAE, Africa, Russia, USA, Germany and other countries.
FEATURES & BENEFITS
- No duct work required
- Filtration assembly filters 99.95% fumes from cabinet
- 24 hours non-stop protection
- Easy to relocation anywhere in laboratory room
- Highly effective carbon and HEPA filters
- Color touch screen controller w/ advanced features
- Equipped with imported VOC sensor
- Various safety alarms
- Full length transparent door w/ lock & keys
- Inn PP material leakage storage sump
- Epoxy coated heavy duty perforated steel shelves
- Industrial grade rugged construction w/ epoxy resin powder coating
TECHNICAL SPECIFICATIONS
| MODEL | STX-G819 | STX-G800 | STX-G1600 |
|---|---|---|---|
| Working dimensions | 753*322*519 mm | 708*450*1750 mm | 1510*450*1750 mm |
| External dimensions | 819*354*725 mm | 800*510*2070 mm | 1600*510*2360 mm |
| Shelves | 2 Nos. | 8 Nos. | 16 Nos. |
| Loading capacity | 3 kg per shelf | 30 kg per shelf | 30 kg per shelf |
| Air capacity | 75m3/4 | 220m3/4 | 220m3/4 |
| Capacity | 40 bottles (500 ml) | 160 bottles (500 ml) | 320 bottles (500 ml) |
| Controller | Color touch screen | Color touch screen | Color touch screen |
| Filters | 1 No. | 4 Nos. | 4 Nos. |
| Sensor | VOC sensor | VOC sensor | VOC sensor |
| Alarm | Yes | Yes | Yes |
| Construction | Epoxy resin powder coated steel sheet | Epoxy resin powder coated steel sheet | Epoxy resin powder coated steel sheet |
| Doors | Acrylic transparent | Acrylic transparent | Acrylic transparent |
| Power supply | 220 Volts 50Hz | 220 Volts 50Hz | 220 Volts 50Hz |
