Autoclave

Large steam sterilizers with automatic sliding doors & pulse vacuum cycles

Pharmaceutical GMP Sterilizer

Pulse Vacuum Sterilizers by STERICOX are especially designed for pharmaceutical production units, CSSD and other applications where stringent quality sterilization is prime requisite. These large steam sterilizers are carefully designed, manufactured and installed at customers' site with complete testing, demonstration and training. Every unit confirms GMP requirement and ideal for sterilization of glassware and containers, various culture and media, filters, seals and garments and fabrics etc.

Our large steam sterilizers are fully automatic in nature and features motor driven sliding door, pre and post vacuum cycles, color touch screen controller with default program settings and various safety features; in addition, these machines can also be customized to meet specific requirements (URS) of our clients.

These pharmaceutical sterilizers are effective for porous and solid products and available in single and double door (pass through) configurations; from 250 liters to 5000 Liters, we can design small to large units as required with single point operation control. Each machine is fitted with PLC based color touch screen HMI controller which features in-built programs for Bowie & Dick test, Vacuum Leak Test, and Liquid Test. There is also option for customized cycle. User can also run machine on manual mode as per his convenience.

Application

  • Culture medium & liquid solution in glass ampoules, vials & bottles
  • Tools, instruments and machine parts
  • Glassware, utensils and containers
  • Cleanroom garments and fabrics
  • Filters, silicon tubes & other accessories


Features & Benefits

  • AISI SS316L sterilization chamber
  • Motor driven sliding type door
  • Shortest batch times and optimum drying
  • Follow stringent pharmaceutical standards
  • Pre and post vacuum cycles
  • Fully automatic operation
  • Safety features for operator & products


TECHNICAL SPECIFICATIONS

Inner chamber Stainless steel 316L
Door Stainless steel 316L
Jacket Stainless steel 304
Outer cabinet Stainless steel 304
Maximum working temperature 134°C
Maximum working pressure 0.23Mpa
Vacuum system Water ring vacuum pump
Controller Color touch screen HMI controller
Printer Mini printer for instant printout
Programs
  • Bowie & Dick test
  • Vacuum Leak test
  • Liquid cycle
  • Customized cycle
Operation mode Automatic / Manual
Door open / closing Motor driven (sliding type) with compressed air
Door gasket High temperature silicone rubber gasket
Air filter 0.22µ sterile filter
Alarms
  • Temperature overshoot
  • Low temperature
  • Low vacuum pressure
  • Low heating rate
Safety features
  • Steam cannot transfer if door not properly sealed
  • Door cannot open under pressure / incomplete cycle
  • Interlocking system for double doors
Optional
  • FDA CFR 21 Part 11
  • Loading trolley
  • Double door
  • On-site validation & documentation


STANDARD SIZES & DIMENSIONS

Inner Dimensions
(W x H x D) mm
Chamber volume Sterilization time Overall Dimensions
(W x H x D) mm
600 x 600 x 700 250 Liters 30 min 1220 x 1720 x 895
600 x 600 x 1000 360 Liters 30 min 1220 x 1720 x 1200
680 x 850 x 1050 600 Liters 35 min 1300 x 1880 x 1245
680 x 850 x 1400 800 Liters 40 min 1300 x 1880 x 1600
750 x 1100 x 1500 1200 Liters 45 min 1370 x 1960 x 1700
750 x 1100 x 3000 2400 Liters 50 min 1370 x 1960 x 3200
1000 x 1500 x 3400 5000 Liters 60 min 1800 x 2200 x 3635
Pharmaceutical GMP Sterilizer
Large Steam Sterilizer
Pulse Vacuum Sterilizer
