This automatic film coating machine is widely used in high temperature film coating research including ceramic films, crystal films, battery material films and special Nano-films. This thin film coating machine comes with doctor plate, film applicator, vacuum aluminum plate, scrapper and heating system. This automatic film coating machine is also used in li-ion Battery Electrode Coating application. It is tabletop machine with small footprints. It is easy to operate and require almost no maintenance. Color touch screen controller is the most advanced feature of this film coating machine. User can set miscellaneous operating parameters with the help of this touch screen controller. A separate PID temperature controller is provided to set heating temperature for drying. We sell this automatic film coating machine at competitive price in India and export.
FEATURES & BENEFITS
- Temperature controlled heating up to 200°C
- In-built timer to set heating time
- 0 to 100 mm coating speed can be regulated
- Vacuum system to hold substrate sheet on aluminum plate
- Stroke length 10 to 250 mm adjustable
- Scraper for regulating coating thickness with accuracy of 0.01mm
- Color touch screen display controller
TECHNICAL SPECIFICATIONS
| Model |
STXFCM-100 |
| Max Stroke |
250mm |
| Power |
650W |
| Stroke range |
10 - 250mm adjustable by using Adjustable Position Switch |
| Vacuum plate |
Equipped with vacuum aluminum plate |
| Coating Speed |
0-100mm/s, Step-less transmission ; Accuracy: 10mm/sec |
| Dimension of vacuum plate |
410*200*30mm (L*W*H) |
| Doctor Blade width |
100mm (other width optional) |
| Regulating range of blade |
0.01~3.5mm |
| Heating temperature |
Room temperature ~ 200°C
PID temperature control w/ LED display & ±1°C accuracy |
| Weight |
45 KG |
| Dimension |
600*310*330 mm (L*W*H) |
| Standard Configurations |
- Applicator
- Oil free vacuum pump
- Horizontal rod
- Feeding box
|
