Key features of animal incinerators may include:
- High-temperature chambers: Animal incinerators are equipped with high-temperature chambers that can reach extremely high temperatures (typically over 1000 degrees Celsius) to ensure efficient and complete combustion of the animal carcasses.
- Secondary combustion: Many modern incinerators have secondary combustion chambers, which further burn any remaining particles and gases from the primary combustion process, minimizing harmful emissions.
- Air pollution control systems: To comply with environmental regulations and ensure the safety of nearby communities, animal incinerators are often equipped with air pollution control systems, such as scrubbers and filters, to reduce emissions of particulates and harmful gases.
- Monitoring and safety features: Incinerators may have sophisticated monitoring systems to control and maintain the optimal temperature, as well as safety features to prevent accidents and ensure the safe operation of the equipment.
- Capacity and size variations: Animal incinerators come in various sizes to accommodate different quantities of animal carcasses, ranging from small-scale units for veterinary clinics to larger-scale units for agricultural or research facilities. Large size animal incinerators come with movable bottom or trolley type.
We are animal incinerator manufacturers in India. We have expertise and knowledge about designing animal incinerator that comply international environmental standards. Standard capacity of animal incinerator available from 20 kg to 500 kg or more. We carefully design each animal incinerator and test at various parameters before dispatch. Our supplies go to all over India, USA, UK, Germany, Greece, Africa, UAE, Philippines, Vietnam etc. at highly competitive price.
Features & Benefites
- 20 kg to 500 kg burning capacity
- Gas and electrically fired
- Meet environmental regulations
- Rugged and durable construction
- Available in wide opening doors
- Designed for high hourly burn rates
- Optional hydraulic door opening & closing
- Supplied with all necessary accessories
- Offer clean & safe bio-secure disposal of animal & animal waste
Technical Specifications
| Model | WPS30 | WPS50 | WPS150 | WPS500 |
|---|---|---|---|---|
| Incineration capacity | 20-30 kg | 50-70 kg | 150-200 kg | 300-500 kg |
| Dimensions of the combustion chamber 1 | 960*580*350 mm | 1250*700*480 mm | 1750*790*650 mm | 2500*1080*1000 mm |
| Feed inlet size (furnace door) | 600*350 mm | 720*480 mm | 810*650 mm | 1100*1000 mm |
| Dimensions of the combustion chamber 2 | 500*600 mm (Dia.*H) | 700*900 mm (Dia.*H) | 800*1020 mm (Dia.*H) | 1300*1510 mm (Dia.*H) |
| Overall dimensions | 1750*1550*1560 mm | 2050*2000*2250 mm | 2900*2100*2570 mm | 3650*2950*3450 mm |
| Chimney (Outside diameter) | 159 mm x 6 meter (Dia.*H) | 219 mm x 6 meter (Dia.*H) | 273 mm x 6 meter (Dia.*H) | 1425 mm x 6 meter (Dia.*H) |
| Oxygen supply fan (power) | 0.37 KW | 0.55 KW | 0.75 KW | 3.0 KW |
| Oil consumption | 2.5-5 kg | 2.5-5 kg | 2.5-5 kg | 5-10 kg |
| Running voltage | 220V OR 380V | 220V OR 380V | 220V OR 380V | 220V OR 380V |
