Induction furnace is exclusively used to melting metals like brass and iron. An induction furnace comprises of a power supply system (frequency generator) and furnace body (crucible holding cabinet and material unloading mechanism). In addition to these parts, some other parts are also required such as cooling tower or chiller. An induction heating furnace is used widely in industrial application and also in universities for laboratory testing purpose.
STERICOX has been active in induction furnace technology for long years. We have experience and good understanding of induction technology to deliver a trusted and reliable induction melting furnace for diverse industry applications. We can design induction melting furnace for brass melting having maximum temperature 1600°C and rated temperature 1100°C and iron melting having 1800°C maximum temperature and rated temperature 1450°C. These induction melting furnaces are supplied with magnesia and graphite crucibles. We have capacity to design an induction furnace from few kg to tons. We supplied induction furnace to all over India with installation and after sales service support. We also export these melting furnaces to USA, Germany, UAE, Greece, Vietnam and Philippines etc. at competitive price.
| Model | Rated Power | Iron, Steel, Stainless Steel, Glass | Brass, Bronze, Copper, Silver, Gold, Zinc | Aluminum, Magnesium |
|---|---|---|---|---|
| Kw | Kg | Kg | Kg | |
| STXIGBT-15 | 15 | 3 | 10 | 3 |
| STXIGBT-25 | 25 | 5 | 20 | 5 |
| STXIGBT-35 | 35 | 10 | 30 | 10 |
| STXIGBT-45 | 45 | 18 | 50 | 18 |
| STXIGBT-70 | 70 | 25 | 100 | 25 |
| STXIGBT-90 | 90 | 40 | 120 | 40 |
| STXIGBT-110 | 110 | 50 | 150 | 50 |
| STXIGBT-160 | 160 | 100 | 250 | 100 |
| Accessories parts |
|
|||
| Options |
|
|||
