In warming cabinets, fluids and solutions are generally warmed to body temperature prior to inflow primarily for patient comfort. These warming cabinets are almost used in every hospitals and clinics to keep blood, medical fluids and blankets warm at body temperature. These cabinets are usually called fluid warming cabinets, fluid warmers or warming cupboards. These medical fluid warming cabinets are made with stainless steel interior and fitted with forced air circulation system and digital temperature controller. These fluid warming cabinets are made in different sizes and design configurations to suit individual needs and suitable for blankets, blood bags and bottles, gel pads, intravenous fluids, peritoneal dialysis (PD) fluid and irrigation fluids etc.
STERICOX™ fluid warming cabinets feature excellent temperature accuracy and over temperature protection to ensure safe warming procedure. There are standard models, you can choose from below table and if you need customized cabinet, our technical team will help you in designing the same cabinet at reasonable price in India.
Detailed Description
- Temperature range: Fluid warming cabinet temperature range remains between ambient+5°C to 90°C.
- Temperature control: The temperature is controlled through PID controller device which is supported by PT100 temperature sensor. This imported controller keeps the temperature accuracy precise.
- Construction: Interior of our fluid warming cabinets are made of stainless steel 304 and exterior is made of powder coated GI sheet. We also make all stainless steel cabinets as an option. Glass wool is used at insulation that minimizes thermal loss and keeps the unit energy efficient.
- Storage: Steel wire mesh cable shelves are standard accessories come with each fluid or blanket warmer; in addition, we also provide basket type sliding drawers as option.
- Air Circulation: Each warming cabinet is equipped with forced air circulation mechanism. A motor driven blower is fitted either top or rear side. It circulates heated air and keeps temperature uniform across the chamber.
Each unit is tested for few days at various steps before dispatching to customer ensuring you that you are buying a finest fluid or blanket warming cabinet with competitive price guarantee in India.
Features & Benefits
- High precision temperature control
- Over temperature protection
- Stainless steel interior
- Removable shelves / drawers
- Glass window on door
- Easy to clean & maintain
- Very quiet operation
TECHNICAL SPECIFICATIONS
| Temperature range |
Ambient+10°C to 60°C |
| Temperature accuracy |
±0.5°C |
| Temperature controller |
- PID temperature controller
- Display SV & PV
- Auto tuning feature
|
| Temperature sensor |
PT100 |
| Inner chamber |
Stainless Steel 304 |
| External cabinet |
Powder coated GI sheet |
| Insulation |
Glass wool |
| Door |
- Insulated door
- Spring latch / clamp
- Glass window
|
| Heaters |
SS finned air heater |
| Shelves |
Wire mesh steel trays (removable) |
| Air circulation |
Axial fan |
| Standard fittings |
- Mains on/off switch
- Load Indicator
|
| Power supply |
220 Volts 50Hz |
| Optional |
- Temperature up to 90°C
- Complete stainless steel construction
- Temperature low / high variation alarm
- Sliding roller type drawers
- LED light inside chamber
- Datalogging of temperature
|
STANDARD SIZES / DIMENSIONS
| Model |
Dimensions (W x D x H) |
Volume (approx.) |
No. of shelves |
| FWC28 |
12 x 12 x 12 inch |
28 Liters |
2 |
| FWC45 |
14 x 14 x 14 inch |
45 Liters |
2 |
| FWC53 |
16 x 16 x 13 inch |
53 Liters |
2 |
| FWC120 |
18 x 18 x 24 inch |
120 Liters |
3 |
| FWC190 |
18 x 18 x 36 inch |
190 Liters |
4 |
| FWC340 |
24 x 24 x 36 inch |
340 Liters |
4 |
| FWC450 |
24 x 24 x 48 inch |
450 Liters |
5 |
