Geer Ovens are aging ovens that are used for testing plastic, rubber and other polymer samples as per ASTM standards. These aging ovens are equipped with forced air circulation and a rotating specimen rack. A digital temperature controller facilitates you to set desired temperature and timer assists you to set dwell time. Specimen rack rotation is 10 rpm. These Geer Aging Ovens offer excellent temperature accuracy and uniformity across the chamber. Rugged construction promises long service life even long continuous use for years. Every components fitted in these aging ovens are from reputed brand from the market offer trustworthy performance. These aging ovens are available for supply throughout India at factory price.
FEATURES & BENEFITS
- Comply ISO, JIS and ASTM standards
- Variable air exchange rate
- Air exchange measurement system
- Rotating specimen rack (hanger)
- Digital temperature controller
- In-built timer for dwell time
- Stainless steel 304 inner construction
- Uniform air flow distribution
- Toughened glass observation window
TECHNICAL SPECIFICATIONS
| Temperature |
Ambient+10°C to 200°C / 300°C |
| Temperature accuracy |
±0.5°C |
| Temperature uniformity |
±2.5°C |
| Temperature resolution |
0.1°C |
| Temperature controller |
PID temperature controller |
| Ventilation |
5 to 300 times/hr adjustable (measured at80°C) |
| Test frame |
Double layered specimen rack |
| Test frame RPM |
8-10 rpm |
| Insulation |
100 mm high density rock wool |
| Inner chamber |
Stainless steel 304 |
| External cabinet |
Powder coated steel sheet |
| Door |
Insulated solid door w/ sturdy handle |
| Observation window |
Toughened glass window |
| Gasket |
High temperature silicone rubber gasket |
| Illumination |
Inner chamber illumination light |
| Safety |
- Over temperature protection
- Fust safety switch
|
| Mounting |
Caster wheels w/ brake |
| Power supply |
220 Volts 50Hz |
STANDARD SIZES / DIMENSIONS
| Model |
Inner Dimensions |
External Dimensions |
Volume |
| AGO100 |
500*450*500 mm |
1050*650*1280 mm |
100 Liters |
| AGO150 |
500*500*600 mm |
1050*700*1350 mm |
150 Liters |
| AGO200 |
600*550*600 mm |
1150*750*1350 mm |
200 Liters |
