High temperature ovens are required by some applications, where high temperature 300°C to 600°C is required. Laboratory research and light industrial applications are some of areas where high temperature ovens play important role. At STERICOX, we have understanding, experience and engineering to design user friendly high temperature oven with temperature ranges up to 300°C, 350°C, 400°C, 500°C and 600°C etc following class 3.1 DIN12880 standards. These ovens are suitable for drying, pre-heating, curing, core hardening, aging and component testing etc. There are variety of customization options are available with us at competitive price in India.
Features & Benefits
- High temperature up to 600°C
- Microprocessor based temperature controller
- Over temperature safety controller
- Uniform temperature distribution across chamber
- Stainless steel inner chamber
- Optimized insulation minimizes heat loss
- Motor driven blower unit
- Tubular air heating element
- Fume exhaust holes
Technical Specifications
| Temperature range |
300°C, 350°C, 400°C, 500°C & 600°C |
| Temperature controller |
PID temperature controller with LED display of SV & PV |
| Thermocouple |
J or K Type |
| Heater |
Tubular air heating element |
| Air circulation |
Motor driven blower with V-belt drive |
| Construction |
Double or Triple walled available |
| Inner chamber |
Stainless steel |
| Outer cabinet |
Powder coated GI sheet |
| Insulation |
High grade ceramic wool & blanket 1200°C |
| Door |
Insulated solid door w/ pull action clamp |
| Gasket |
High temperature ceramic rope & Silicone rubber gasket |
| Trays |
Chrome plated stainless steel trays |
| Exhaust |
Fume exhaust holes |
| Power supply |
220 / 440 Volts 50Hz |
| Optional |
- Over temperature safety controller
- External cabinet made of SS304
- GMP model (Inner SS316 & Outer SS304)
- Timer or profile control
- Door safety limit switch
- Data recording w/ Date, Time & Temperature
- Eurotherm temperature controller
|
Standard Sizes / Dimensions
| MODEL |
INNER DIMENSIONS (W x D x H) |
NO. OF TRAYS |
| STXHTO28 |
305 x 305 x 305 mm |
2 |
| STXHTO45 |
355 x 355 x 355 mm |
2 |
| STXHTO95 |
450 x 450 x 450 mm |
2 |
| STXHTO125 |
450 x 450 x 600 mm |
3 |
| STXHTO225 |
600 x 600 x 600 mm |
3 |
| STXHTO340 |
600 x 600 x 900 mm |
3 |
| STXHTO450 |
600 x 600 x 1200 mm |
4 |
| STXHTO760 |
914 x 914 x 914 mm |
4 |
| STXHTO1000 |
1000 x 1000 x 1000 mm |
4 |
