Laboratory Deep freezers play important role in safe storage of reagents, frozen vaccines and other temperature sensitive specimens for research purposes that require freezing temperature up to -20 degree. These freezers are ideal for routine storage of samples in the clinical, pharmaceutical and biomedical laboratories.
We are CE and ISO certified laboratory deep freezer manufacturers in India and our company designs laboratory deep freezers in minus 20 degree temperature range. These freezers are ergonomically designed to meet critical freezing storage requirements of life science laboratory, pharmacy and biomedical lab etc.
These units are designed in either vertical (upright) or horizontal designs. Each unit is fitted with digital temperature controller for easy temperature settings; other accessories that may include are temperature chart recorder, data logger, buzzer alarm and caster wheels etc.
If you are looking to buy a customized laboratory deep freezer, STERICOX is the name you can trust. We have in-house deep freezer manufacturing facility (factory), which is equipped with latest machines. Our engineering team has years of experience in deep freezer construction which enables us capable of designing any size of deep freezer you need for your application. Just discuss your requirements with our team; we can make the exact machine at factory price.
TECHNICAL SPECIFICATIONS
Temperature |
-20°C |
Capacity |
120, 170 liters, 280 liters, 340 liters, 450 liters, 700 liters or more |
Design configuration |
Vertical / Horizontal |
Outer cabinet |
Powder coated MS |
Inner chamber |
Stainless steel 304 |
Door |
Solid insulated door with lock & key |
Gasket |
Magnetic rubber gasket |
Insulation |
Polyurethane Foam (PUF) insulation |
Shelves |
SS wire mesh removable type |
Refrigeration |
Hermetically sealed compressors
with CFC free refrigerant |
Defrost type |
Manual |
Controller |
Digital temperature controller w/ LED display |
Sensor |
NTC |
Alarm |
Audiovisual alarm for high / low set points |
Power supply |
220V/50Hz |
Mounting |
Caster wheels w/ brake |
Optional |
- Door open alarm
- Data logger with USB port
- Temperature chart recorder
- Voltage stabilizer
|
Standard Sizes / Dimensions
MODEL |
INNER DIMENSIONS
(W*D*H) |
VOLUME |
SHELVES |
STXDF20-120 |
450*450*600 mm |
120 Liters |
2 Nos. |
STXDF20-170 |
550*500*600 mm |
170 Liters |
2 Nos. |
STXDF20-280 |
550*550*900 mm |
280 Liters |
3 Nos. |
STXDF20-340 |
600*600*900 mm |
340 Liters |
3 Nos. |
STXDF20-450 |
600*600*1200 mm |
450 Liters |
4 Nos. |
STXDF20-600 |
700*700*1200 mm |
600 Liters |
4 Nos. |
STXDF20-1000 |
1070*670*1515 mm |
1000 Liters |
4 + 4 Nos. |
