These minus 40 degree deep freezers are available in upright (vertical) shape and ideal for biomedical applications including blood plasma storage and other specimen that require extreme low temperature -30°C or -40°C. We have both economy and premium models; with aluminum inner chamber and stainless steel inner chamber respectively. Model DW-FL270 is economical blood plasma freezer, which comes with aluminum with spray paint inner chamber that can accommodate 7 ABS drawers. Model DW-FL439 is premium model and comes with stainless steel 304 inner chamber, which can accommodate 14 ABS drawers. Both models have powder coated steel sheet exterior cabinet. Model DW-FL439, has some extra features such as 72 hours battery backup for controller and USB data logger for temperature monitoring. Both blood plasma freezer models are economical in price and supply all India with complete installation, demonstration and exciting warranty periods.
FEATURES & BENEFITS
- -10°C to -40°C temperature range
- Vertical / Horizontal design available
- Data recording with USB interface
- Various types of safety alarms
- Inner and outer solid doors
- Stainless steel solid shelves
TECHNICAL SPECIFICATIONS
Cooling performance |
-40°C |
Temperature range |
-10°C to -40°C |
Temperature controller |
Microprocessor temperature controller |
Construction |
Double walled |
Interior |
Stainless steel 304 |
Exterior |
Powder coated MS |
Insulation |
Thick PUF insulation |
Inner door |
Stainless steel 304 inner door |
Outer Door |
Insulated solid door with lock & key |
Trays |
Stainless steel 304 solid trays |
Refrigeration |
Hermetically sealed compressor (EMERSON / TECUMSEH make) |
Safety |
Temperature High / Low alarm |
Power |
220 Volts / 50 Hz |
Mounting |
Caster wheels with brake |
Optional |
- Horizontal / Chest / Top loading design
- Stainless steel exterior
- Door open alarm
- Data logger with USB interface
- PLC with HMI interface
- Battery backup system for controller display
|
STANDARD SIZES / DIMENSIONS
Model |
Volume (Liters) |
Dimensions (W*D*H) |
SHEVLES |
STXDF40-120 |
120 Liters |
450 x 450 x 600 mm |
2 Nos. |
STXDF40-170 |
170 Liters |
400 x 500 x 845 mm |
2 Nos. |
STXDF40-340 |
340 Liters |
600 x 600 x 900 mm |
3 Nos. |
STXDF40-500 |
500 Liters |
675 x 620 x 1200 mm |
4 Nos. |
STXDF40-700 |
700 Liters |
770 x 760 x 1200 mm |
4 Nos. |
